■ How to install and use

Installing ORIGAMI

  1. Install ORIGAMI on the machining center according to the procedure.
  2. Check the machining model and determine the first reference surface to be cut, then create dedicated jig data for ORIGAMI.
  3. Attach the workpiece material to the first unit of ORIGAMI and the jig material to the second unit.



Automatic Machining

  1. The second unit first rotates 90 degrees and processes the jig necessary to fix the material
  2. Processes the jig
  3. Cuts the first machining surface of the material
  4. The first unit processes the second machining group (vertical surfaces) by repeating rotation and cutting
  5. The second unit rotates closer and fixes the material with the jig it has created
  6. Starts cutting away from the first unit
  7. The second unit, which has fixed the material with the jig, finishes and cuts the final surface






Automation system "CMX 600 V + ORIGAMI + MATRIS mini"

Examples of micro forceps parts made by ORIGAMI
